SelfLoading Concrete Mixer (0.5-6.5m3)

Self loading concrete mixer is combine concrete truck mixer with concrete mixer, self loading concrete mixer can automatic feeding, metering, and mixing to discharge, and more。

It can realize the transportation and site construction operations, which greatly improves the work efficiency, reduce production cost and time.

UNIQUEWhat are the features of concrete mixer?

Self-Loading: The truck is designed to scoop aggregates, water, and cement directly from the ground or stockpiles, reducing the need for additional equipment.

Compact Design: Its compact size makes it ideal for maneuvering in tight construction sites, ensuring flexibility in operation.

High Mixing Efficiency: The truck features a powerful mixing drum that ensures thorough and uniform mixing of concrete, resulting in consistent quality.

Get a free quote

Parameters of Self loading Concrete Mixer:

What is the capacity of a self-loading concrete mixer?

The 270° rotating chassis can adapt to narrow construction sites, the hydraulic system can transport materials stably,

Generally, the output volume is the capacity of the mixer. Most self loading mixers models are named by their capacity, the self loading mixers can produce 0.5m3, 1.2m3, 2m3, 2.6m3, 3.5m3, 4m3,5.5m3 and 6.5m3 concrete per batch separately, which increases efficiency by 300%!

Get A Quote

Model	*Overall Dimensions (LWH)*	Wheel base(mm)	Curb Weight(kg)	Engine Rated Power	Mixing Drum Capacity	Drum Rotation Speed	Concrete Yield
0.5m3	420016002350	1500	1860	16KW	700L	18-21rpm	0.5m3/Batch
0.8m3	338928762295		3620		1450L		0.8m3/Batch
1.2m3	730018003450	2560	4920	58KW	1700L	13rpm	1.2m3/Batch
2m3(270)	695027203850	2520	6300	75KW	3500L	18-21rpm	2.0m3/Batch
2.6m3(270degrees)	786027504100	2800	7000	75KW	3000L	13rpm	2.0m3/Batch
3.5m3A(270degrees)	783026804170	2900	7800	85KW	4740L	18-21rpm	3.5m3/Batch
3.5m3D(180degrees)	759026004270	2687	8050	85KW	4740L	18-2lrpm	3.5m3/Batch
4m3(270degrees) Aiticulation Synchronization	845030004500	3300	9700	91KW	6000L	20rpm	4.0m3/Batch
4m3(290degrees) Overall fiame	764028704750	2480	9000	91KW	6000L	18-21rpm	4.0m3/Batch
5.5m3(270degrees)	845031004580	3350	11200	92-132KW	7800L	20rpm	5.5m3/Batch
6.5m3(290degrees) Overall fiame	845030504830	2850	12520	92-132KW	9000L	16.5rpm	6.5m3/Batch

Working processing of Self Loading Concrete Mixer

Get A Quote

Step 1.

by charging scoop,small amount of sand and gravel is loaded into the mixing drum

Step 2.

self-loading concrete mixer interior injected into water, when the supply water flow is completed, adding cement, self-loading concrete mixer will run to the designated place to unload concrete, at the same time, the mixing drum will keep rotating to ensure that the concrete dose not condense.

Step 3.

mixing drum is equipped with the screw type of blade,, the maximum savings in working time and raw material

Step 4.

After working, the completion of the need for equipment to be cleaned to ensure that the normal work in the future.

What is the use of self loading concrete mixer?

What are the applications of concrete mixer?

This innovative truck offers significant benefits, including time savings, reduced labor costs, and increased productivity. It is an essential tool for small to medium-sized construction projects, can be used in special construction projects such as high-speed railways, bridge tunnels, and township level highways. It can also be used for plant maintenance and repair. Providing a reliable and efficient way to produce concrete on-site.

Get A Quote

3.5m3 Self Loading Concrete Mixer in Maldives

4m3 Self Loading Concrete Mixer in Mexico

2.6m3 Self Loading Concrete Mixer in Ghana

3.5m3 Self Loading Concrete Mixer in East Timor

2.6m3 Self Loading Concrete Mixer in Australia

1.8m3 Self Loading Concrete Mixer in Peru

Why choose our self-loading concrete mixers?

Our state-of-the-art self-loading mixers offer unparalleled convenience and efficiency in construction projects. With a built-in loading, mixing, and transportation system, and only requires one person to operate. they significantly reduce labor costs and construction time. Our mixers are designed for rugged terrain, ensuring smooth operation even in challenging environments. With a commitment to quality and innovation, we guarantee superior performance and durability. Choose our self-loading mixers for a streamlined construction process, enhanced productivity, and a reliable partner in your building projects.

‌Efficiency‌:

These mixers combine the functions of transporting, mixing, and pouring concrete into a single unit. This integration allows for a more streamlined process, reducing time costs and enhancing productivity. By performing both mixing and transportation simultaneously, they significantly save time and labor compared to traditional concrete transportation methods‌.

‌Versatility‌:

Self-loading concrete mixers are highly mobile and flexible. They can easily access construction sites where concrete pouring is needed, providing efficient service to builders. Additionally, they minimize disruptions to road traffic and noise pollution for nearby residents‌.

‌Cost-Effectiveness‌:

The use of self-loading concrete mixers can lead to overall cost savings. By automating the mixing process, they reduce the need for additional labor and equipment. Furthermore, the maintenance of concrete quality and uniformity throughout transportation ensures that less material is wasted, further contributing to economic benefits‌.

In summary

Our self-loading concrete mixers are an excellent choice for their ability to enhance efficiency, versatility, and cost-effectiveness in concrete transportation and processing.

Get A Quote
