YLB Mobile Asphalt Plant

该产品后台详情无内容

YLB Asphalt Mixing Plant

Asphalt mixing plant is a plant that is used for mixing the dry warm aggregate, padding and asphalt for homogeneous mixture at the required temperature. What should be mentioned here is that mixing the aggregate, padding and asphalt must be at a certain proportion. And it is widely used to the construction of highway, city road and parking lot.

UNIQUEYLB Asphalt Mixing Plant

Model Number: LB700-LB2000

Capacity: 60 t/h ~ 160 t/h

Mixer Capacity: 700 kg/batch ~ 2000 kg/batch

Highlights:
Mobile plant,easy for installation, fast relocation;
Batch mix, precise screening, accurate weighing.

Parameters

ModelYLB700YLB1000YLB1500YLB2000
Capacity(t/h)6080120160
Mixer Capacity(kg/batch)750100015002000
Drum dryer(mm)dia.1200*5200dia.1600*6800dia.1800*8000dia.2200*8500
Dust collect effect≤20 mg/Nm3≤20 mg/Nm3≤20 mg/Nm3≤20 mg/Nm3
Total Power(kw)178285380470
Fuel Consumption (Oil)5.5-7kg/t5.5-7kg/t5.5-7kg/t5.5-7kg/t
Fuel Consumption (Coal)10kg/t10kg/t10kg/t10kg/t
